HM232D-125 Miniature Circuit Breaker (DC MCB) 10kA

Products

Our MCB breaking capacity is up to 10-15KA , the DC

voltage for MCB MCCB SPD is up to 1500V.

❮

❯

Contact position indicator window, with clear working status at a glance

Rail type installation, with a large travel of the installation buckle, the product can be quickly replaced after installation

Meet the energy level 3 requirements of the EU EN standard to enhance the safety of electrical systems

Complete accessory configuration

Optional breaking capacity of 6kA/10kA

DC has no polarity and the maximum voltage reaches DC1000V

Product Details
