Our MCB breaking capacity is up to 10-15KA , the DC
voltage for MCB MCCB SPD is up to 1500V.
For installation at LPZ0A-1 or higher, protecting low voltage equipment against lightning and surge damages.
Appliedin PsD class l+ll(Class B+C) for various power supply system. Designed accordingto lEC 61643-1/GB 18802.1.
•10/350us,8/20us sparkgap
•Single-pole lightning current arrester, pluggable
•Adopt hermetical GDT technology, high follow current extinguishing capability
•Extremelylow voltage protection level
•Double terminals for parallel or series (V-shape) connection.
•Multifuntional connection for conductors and busbars.
•Green window will change to red when fault occurs, also provide remote alarmterminal at the same time
•For using high-performance MOV and maximum will up to 10/350 12.5kA
